Commercial and Residential Co-Pilot Meter Bypass System

The Co-Pilot meter by-pass system allows a gas meter to be safely and easily replaced without interrupting service or the need to enter a residence. No more scheduling and rescheduling to re-light pilots or conduct appliance checks. It requires no hoses or regulators or complex combinations of valve procedures.

It quickly connects to virtually any existing 8.25" for Commercial and 6" for Residential on-center meter set, whether it's composed of a prefabricated steel set or a malleable meter bar combined with swivels and nuts. It's adaptable to many combinations of meter nuts. Its aluminum body is coated with a UV resistant gas gray polyester to keep unit looking good and protected for years of service. The Co-Pilot is self-contained. It is tamper-proof, with a custom activation key, and optional locking devices that provide multiple levels of security.

The Co-Pilot provides a user-friendly gas meter bypass and purge solution. The Co-Pilot can be used on new or existing installations.

Once installed, meters can be bypassed and serviced without gas supply interruption to the property. Options include a locking cap device or custom lock assembly and key for by-pass.


  • Pressure rating: 25 psi max
  • Working temperature range: -30°F to 120°F
  • Pressure rating: 10 psi max
  • Working temperature range: -30°F to 120°F

Please accept all cookies to view the youtube video content.

Features and Benefits

Part Numbers

Male Swivel Meter Bypass Part Numbers

Without Lock Plate
With Lock Plate
Without Lock Plate With Lock Plate
Item Description Item Description
360063631 20LT×6.00 C/C 360064360 20LT×6.00 C/C
360063632 1A×6.00 C/C 360064361 10LT×6.00 C/C
360063633 1.25×6.00 C/C 360064362 1A×6.00 C/C
360063634 10LT×6.00 C/C 360064363 1.25×6.00 C/C
360064359 30LT×6.00 C/C 360064364 30LT×6.00 C/C

Commercial Co-Pilot Part Numbers

With Lock Plate
With Lock Plate
Item Description
360092849 30LT x 8.25 C/C
360092850 45LT x 8.25 C/C
360063635 *ACTUATION KEY
