Precise water control

Hycleen Automation System

Revolutionizing sanitary automation processes and securing the safe supply of potable water

Speak to an Expert

The Hycleen Automation System conducts your potable water installation safely and conveniently from one central control unit. With the automated circulation control system, GF Piping Systems ensure flowing harmony in your installation. It allows for all system data to be logged, evaluated and displayed on a 10-inch touch screen. All system data can be conveniently monitored remotely; status information and unusual occurrences are reported via push messages.

Hygiene

Uniformly high temperatures and regular water exchange. Prevention of biofilm formation and Legionella infestation thanks to hydraulic balancing and automatic flushing.

Comfort

Easier calculation of hydraulic balancing thanks to sound data basis and thus constant water pressure, without long waiting time for cold or hot water.

Energy saving

Hot water temperature reduction thanks to optimal hydraulic balancing.

Simplicity

Simple to install with only one cable for electricity and data. Fast, software-assisted commissioning. Master automatically detects type and ID of all connected controllers.

How it works

Hot Water Energy Calculator

Use the Hot Water Energy Calculator from GF Piping Systems to calculate for each building the energy consumed by the drinking water installation, the CO2 emissions and the energy costs. With just a few clicks, the free online calculator tells you how much you can save by optimizing the drinking water installation. Here lies a huge savings potential that is still grossly underused.

Components

Central control of all Hycleen valves in the drinking water system Hycleen Automation System Master

Master

The Hycleen Automation Master controls up to 50 controllers on two cable harnesses (each 500 m). During commissioning, the Master detects all valves and sensors in the system with ID and type and assigns them to the appropriate applications.

Flow sensor for measuring the volume and speed of the water, T-sensor for temperature and drain monitoring for a safe flushing process. Hycleen Automation System Sensors

Sensors

All sensors are recognized automatically, they do not have to be parameterized. The T-sensor monitors temperatures at additional points such as the boiler input/output.
The flow sensor on the circulation valve allows hydraulic balancing by measuring speed or volume. The flow monitoring provides even more safety during flushing processes and prevents flooding.

Gunmetal valves with integrated controller for connectivity with the master for circulation and flushing. Hycleen Automation System Valve

Valves

The LegioTherm 2T and LegioTherm K valves, together with the Master, are at the heart oft the Hycleen Automation System. Water temperature readings are permanently taken by the valves; the values are passed on to the master.
The valves are activated dependent on preprogrammed parameters. During commissioning, all valves are automatically detected by the Master by their ID.

Water now comes from the cloud

Discover the new Hycleen Connect.

  • Remote monitoring
  • Alerting
  • Remote access
  • Data management
Learn More

Automated solution for building water systems

Hycleen Automation System is improving water safety and performance in hospitals by creating a more intelligent, automated control system. Watch the Community Hospital of Staunton reference case video.

Download Reference Case

Reference Cases

Learn More

Hot water back in balance

The Community Hospital of Staunton, Illinois, is a critical access hospital in the state’s southwest region. The hospital’s facility director approached GF Piping Systems for assistance with the balance of the building’s water system. The goal was to resolve long wait times for hot water and difficulties with reaching desired temperatures.

Learn More Building with large H sign for hospital

Finding an Automated Solution for Building Water Systems

When Miami Valley Hospital evaluated their domestic hot water system, they realized they were experiencing low return water temperatures. They turned to HEAPY, a nationally recognized engineering leader in healthcare to find a solution. Find out why they chose the Hycleen Automation System.

Reference Hycleen Automation System

„We sought an integral solution, not just one for the water intake“

Moss municipality was recently able to put two new systems into operation that will reduce the risk of Legionella or other unwanted bacteria occurring within the hot water supply. This solution will ensure that the system will be regulated at all times and that its operation will be documented
