SYGEF® Standard PVDF components are distinguished by their outstanding chemical resistance to a variety of aggressive media and excellent temperature resistance up to 284°F. Thanks to the use of selected raw materials made from fluoropolymers, these products can also be used in harsh conditions, such as corrosive environments or strong sunlight. System components are quickly and securely connected by socket, butt, infrared or bead and crevice-free welding.
- d20 - d315 mm (½" - 12")
- d20 - d110 mm: PN16 (232 PSI)
- d160 - d315 mm: PN10 (150 PSI)
- -20°C - 140°C (-4°F - 284°F)
- Polyvinylidene Fluoride (PVDF)
Excellent chemical and thermal resistance to various aggressive chemicals, such as those frequently used in the chemical process industry, water treatment, and microelectronics.
PVDF offers exceptional weather resistance. Even prolonged exposure to sunlight, wind, rain or corrosive environments will not damage the material.
Fast and reliable welding using a range of fusion jointing technologies: The optimal jointing technology is available for every application and its requirements with regard to space, installation time and quality specifications.
PVDF's fire resistance is self-extinguishing, even without the use of fire protection additives.
Sturdy and lightweight, plastic pipes are ideal for use in a wide range of applications. Versatile yet durable, these all-rounders offer exceptional reliability and proven quality.
Adapters and transitions are essential for connecting metal with plastic pipes or even two plastic pipes. This range covers multiple materials and offers reliable connections while offering high flexibility during assembly.
Bends and elbows are essential fittings that easily change the direction of pipes. The extensive range available offers not only multiple materials but also different curvature degrees to easily fit your piping system.
Caps provide a tight seal and stop the flow direction of a piping system. GF Piping System caps are available in different dimensions, different plastic materials and malleable iron to fit all of your needs. Temporary caps ease the pressure testing of an installed pipeline.
Simplify the pipe installation process with couplers and sockets. Specially designed to slide easily over pipes with no extra equipment required, they are cemented, welded or mechanically connected to create a pressure-tight joint.
Flange connections are often the best mechanical connection between pipe segments or for installing valves up to very big dimensions.
GF Piping Systems has an extensive range of installation fittings available in a wide range of materials, ensuring secure and accurate positioning of sensors and electrodes for exceptional performance. The fittings match perfectly with all GF Signet products and are key for the easy installation of measurement equipment.
Reducers are used for effecting a smooth transition between two pipes or fittings with different dimensions. The wide selection available covers an exceptionally diverse area of applications. They are available in short or long versions and in centric or excentric versions.
When creating branch lines, lightweight tee, wye, and cross fittings make installation much easier. These fittings are made from a range of materials and malleable iron and cover multiple dimension possibilities including various reductions on the same fitting.
Unions are the best mechanical connection between pipe segments and for installing all kinds of components up to the dimensions of d110/DN100. Unions are available in a wide range of materials and jointing options. The connection is fast and very robust.
The original just got better.
The ball valves from GF Piping Systems do not compromise on safety. Special design features ensure high reliability and long service life. For example, there are no metal components in areas that are in contact with the medium that could corrode during use. A predetermined break point integrated in the stem interface prevents leaks due to wear or excessive force. Two o-rings integrated into the stem interface provide maximum protection.
As the successor of the proven original, the Ball Valve 543 Pro has been improved in many ways. A reinforced security break point in the stem interface prevents leaks due to wear or excessive force. Two integrated sealing rings in the stem interface provide double safety. Therefore, the 543 Pro offers uncompromising reliability and can be flexibly expanded with optional accessories. All previous quality features of the ball valves have been migrated to the new generation.
The advantage of Ball Valve type 523 is exact dosing of small quantities of media. Its circular scale and specially shaped ball enable precise dosing. It serves for small volumes for which a linear flow is required and a sudden increase in flow are not.
Lightweight, robust and with compact dimensions, the Laboratory Ball Valve 522 is ideal for use in applications where space is at a premium. It is extremely easy to install and available in metric and imperial configurations.
Intended for use in numerous applications from chemical processing to water treatment, GF Piping System offers a wide range of diaphragm valves. This includes manual, pneumatic and electric operation combined with all plastic and diaphragm materials.
GF Piping Systems Type 578 butterfly valves with high corrosion resistance are perfect for use in chemical processing and industrial water treatment. Their versatile design minimizes torque and allows them to be used as a wafer-style or lug-style valve.
A modular design and an intelligent yet simple operating principle make the GF Piping Systems Type 567 butterfly valve the perfect addition to any set-up. This wafer-style butterfly valve is made of highly durable, corrosion-resistant plastic and can be installed with ease.
The Cone Check Valve 561/562 is designed to prevent the backflow of media into sensitive systems. This valve minimizes pressure loss and comes with a special seal to guarantee leakproof operation.
Large installations require a valve that is simple to insert and maintain, which is why GF Piping Systems developed the Wafer Check Valve Type 369. It can be installed horizontally or vertically and guarantees excellent flow characteristics.
Light, compact and available for a range of piping configurations and tanks, GF Piping Systems Ventilating & Bleed Valve Type 591 ensures reliable venting of liquids and gases, preventing media backflow and jamming.
Intended for use in aeration systems, the Ventilating Valve Type 595 ensures safe venting of liquids and gases in the event of negative pressure. This valve is easy to install, while the robust materials and excellent reliability minimize maintenance.
Durable, dependable and simple to use, the Type 582 Pressure Reducing Valve’s design reduces the pressure on the outlet of the valve. It is used to reduce higher pressure from main lines or to protect sensitive devices from being damaged by too much pressure.
The V82 Pressure Reducing Valve is made of durable, corrosion-free plastic and contains an actuator that is hermetically sealed against aggressive media in the pipe system. The innovative design allows it to be installed in virtually any position. This valve is also made for pipes of bigger dimensions.
Also known as an overflow, safety or backpressure valve, the Type 586 Pressure Retaining Valve works to keep the pressure at the valve inlet constant at all times, thereby ensuring problem-free operation. Made of fully molded, high-grade plastic, this is an intelligent addition to any piping system.
The V86 Pressure Retaining Valve works to keep the pressure at the valve inlet constant at all times, ensuring problem-free operation of the system as a whole. It is made for pipes of larger dimensions.
Made from corrosion-resistant plastic and suitable for use in a wide range of applications, GF Piping Systems solenoid valves offer unparalleled reliability.
For efficient throttling of media in piping systems and flawless operation, look no further than the GF Piping Systems Type V251 throttle valve. Made of high-grade, durable plastic, this compact valve is highly resistant to corrosion and chemicals.
P20 self-priming water jet suction pumps from GF Piping Systems have no mechanically moving parts, making them extremely compact and reliable. Thanks to the corrosion-resistant molded plastic design, they are ideal for mixing, dosing and handling liquids.
Paddlewheel flow sensors are highly repeatable, rugged sensors that offer exceptional value with little or no maintenance.
GF Signet Magmeters are versatile, easy-to-install sensors with no moving parts and patented Magmeter technology.
The BCF fusion machines made by GF Piping Systems stand up to the highest requirements in terms of quality and purity for fusion joints. The machines are ideal for high-purity applications in the pharmaceutics, biotech, foodstuffs, process and microelectronics industries.
Robust, lightweight and practical, the MSA 2 series features a barcode scanner, a cooling system for multiple jointing operations and ample internal memory for storing records. An intuitive interface gives the operator a clear overview at all times.
Simple to operate and featuring a robust aluminum housing, the MSA 315, 330 and 340 electrofusion units control the entire welding process taking into account energy output compensation. These units also have sufficient internal memory to store up to 1,000 jointing records.
IR fusion machines, designed and produced by GF Piping Systems, meet the highest demands of mechanical stability, reproducibility and quality of fusion jointing. Typical application areas include the process and microelectronic industry.
Designed for stress-free installation with minimal movement during the welding and cooling process, these tools can be clamped into position with ease. The GF Piping Systems range includes multiple innovative variants for maximum practicality.
If a pipe needs to be cut exactly, it is essential to have a cutting tool that is up to the job. The GF Piping Systems range comprises state-of-the-art cutters that can cut many different pipe sizes and materials properly and quickly.
GF Piping Systems takes the hassle out of peeling and chamfering. Easy to use peeling tools ensure consistent peeling quality when preparing pipesurfaces while chamfering tools are designed to chamfer pipes of various diameters in no time at all.
Original, high-quality spares parts for GF Piping Systems systems and products. Spare parts are available throughout the lifecycle of your system and available in an agreed timeframe.
We provide a wide range of accessories to support your installation projects. Accessories are available for use throughout the life-cycle of your system and available in an agreed time-frame.
Thanks to continued innovation efforts, we are continually improving and refining our products and systems. Due to this, some fittings are no longer being manufactured. If you are unsure if a product line you currently own is discontinued, or are looking for support or further information on one of our discontinued product lines, please find our contact information below.
Thanks to continued innovation efforts, we are continually improving and refining our products and systems. Due to this, some valves and actuators are no longer being manufactured. If you are unsure if a product line you currently own is discontinued, or are looking for support or further information on one of our discontinued product lines, please find our contact information below.
