Controllers

GF Urecon offers electronic and mechanical thermostats for your heat tracing needs.

Smart Control, Maximum Protection: The Benefits of Thermostats in Heat Tracing Systems

Thermostats used alongside heat tracing cables provide precise temperature control, ensuring that systems maintain optimal performance without unnecessary energy use.

By automatically activating the heat trace only when needed, thermostats help prevent freezing, maintain fluid temperature, and extend the lifespan of both the cables and the piping system.

This smart control reduces energy costs, minimizes the risk of overheating or heat loss, and improves overall system reliability.

For industries operating in harsh climates, thermostats add an extra layer of safety and efficiency, making heat tracing solutions more sustainable and cost-effective.

GF Urecon offers a range of both electronic and mechanical thermostats to meet a wide range of industries, applications and customer specifications.

Electronic Controllers

These models can be fitted with up to three temperature sensors as required by the application. Because seperate temperature sensors are used, they may be installed on the pipe during the initial installation phase while the controller itself may only be installed at a later date.

Features

Designed by GF Urecon - Made in Canada
OLED Display
USB port for programming
Communication capabilities
Multiple cards in one enclosure for multi points system
Options: Bigger enclosure, heaters, Nema 4X, junction boxes, etc.. contact us

NGUTC-2030 and NGUTC-2230 Thermostats

Model No. NGUTC-2030-(program code #)
Model No. NGUTC-2230-(program code #) with circuit breaker

This state-of-the-art electronic thermostat is designed to control one or more heating cables operating between 120 and 240 Vac having a total current draw that does not exceed 30 A. It can be fitted with up to three temperature sensors as required by the application. Because separate temperature sensors are used, they may be installed on the pipe during the initial installation phase while the controller itself may only be installed at a later date.

Three-Phase Contactor Thermostat

Model No. NGUTC-V3AA-(program code #)

This state-of-the-art three-phase electronic thermostat is designed to control heating loads up to 600 Vac having a total current draw not exceeding 60 A. It can be fitted with up to three temperature sensors as required by the application. Because separate temperature sensors are used, they may be installed on the pipe during the initial installation phase while the controller itself may only be installed at a later date.

Mechanical Controllers

Mechanical Thermostat

Model No. URTH-3608 (for metal pipe)

This model is a cost effective CSA approved capillary type thermostat used to control short lengths of THERMOCABLE®. Remote bulb type with adjustable temperature range 0°C to 50°C (32°F to 122°F), ambient compensated with a differential of ±2.2°C (3.75°F).

Rated at 30A, 120/240 Vac, 3 m (10 ft) capillary.
Capillary is permanently attached to the control and may not be lengthened
SPST contacts open on temperature rise.

Model No. URTH-3616

Similar to URTH-3608, except 7.6 m (25 ft) capillary.

Electrical Accessories

GF Urecon provides temperature sensors and electrical accessories such as indicator lights and more, delivering the reliability and flexibility needed for any heat tracing application. Contact us with your requirements.

We also offer a full range of Heat Trace accessories to support Thermocable installations such as power and end termination kits, splice kits, power feed kits, and custom power feed solutions—ensuring secure and efficient connections every time. Check it out here.
