ABS products provide one of the most energy-efficient solutions for industrial applications in a temperature range from 60°C to -50°C. The low thermal conductivity increases the energy efficiency of the system and makes it easier to achieve environmental targets. In addition, the cement jointing technology makes installation simple, fast and secure.

value-bar-icon-2 Safe even below zero

The high impact strength even at low temperatures increases the safety of the system. The system is particularly robust against sudden external impact, even below 0°C.

Reduced maintenance costs

Excellent resistance to a wide range of coolants, such as glycols, and a minimum service life of 25 years reduces your maintenance costs.

Easily installed

Fast, simple and permanently secure connection using cement. The compact design with convenient axle spacing saves time and effort.

Free of halogens

The ABS system is halogen-free, meaning it is usable in markets such as shipbuilding, and offers a broad spectrum of chemical resistance.

Adapters & Transitions

Adapters and transitions are essential for connecting metal with plastic pipes or even two plastic pipes. This range covers multiple materials and offers reliable connections while offering high flexibility during assembly.

Bends & Elbows

Bends and elbows are essential fittings that easily change the direction of pipes. The extensive range available offers not only multiple materials but also different curvature degrees to easily fit your piping system.

Butterfly Valve 567

A modular design and an intelligent yet simple operating principle make the GF Piping Systems Type 567 butterfly valve the perfect addition to any set-up. This wafer-style butterfly valve is made of highly durable, corrosion-resistant plastic and can be installed with ease.

Butterfly Valve 578

GF Piping Systems Type 578 butterfly valves with high corrosion resistance are perfect for use in chemical processing and industrial water treatment. Their versatile design minimizes torque and allows them to be used as a wafer-style or lug-style valve.

Caps & End Caps

Caps provide a tight seal and stop the flow direction of a piping system. GF Piping System caps are available in different dimensions, different plastic materials and malleable iron to fit all of your needs. Temporary caps ease the pressure testing of an installed pipeline.

Couplers & Sockets

Simplify the pipe installation process with couplers and sockets. Specially designed to slide easily over pipes with no extra equipment required, they are cemented, welded or mechanically connected to create a pressure-tight joint.

Diaphragm Valve 317

Large-scale pipes require a diaphragm valve with equally large dimensions, which is why the GF Piping Systems range includes the Type 317. Fitted with a graduated optical position indicator, the proven screw design provides excellent flow control.

Diaphragm Valve 514

Intended for use in numerous applications from chemical processing to water treatment, GF Piping Systems Type 514 diaphragm valves offer very linear flow characteristics with the highest flow rate available on the market. The true union connection of the Type 514 allows for fast installation and exchange.

Diaphragm Valve 515

Intended for use in numerous applications from chemical processing to water treatment, GF Piping Systems Type 515 diaphragm valves offer very linear flow characteristics with the highest flow rate available on the market. The spigot of the Type 515 allows for durable installation with no dead space.

Diaphragm Valve DIASTAR 025

Large-scale pipes require a pneumatic diaphragm valve with equally large dimensions, which is why the GF Piping Systems range includes the Type 025. Fitted with an intuitive accessory interface, the proven screw design provides excellent flow control.

Diaphragm Valve DIASTAR Six

Engineered specifically for low-pressure applications, DIASTAR Six diaphragm valves are a cost-effective solution wherever top reliability, zero corrosion and optimized flow are required. The compact dimensions make them easy to install and remove.

Diaphragm Valve DIASTAR Ten

The ideal fail-safe diaphragm valve for standard applications, the DIASTAR Ten is highly resistant to chemical corrosion and suitable for use with abrasive media. Rotatable air connections make installation simple, while multiple accessories are available for enhanced performance.

Diaphragm Valve DIASTAR Ten Plus

For applications in which pressure is applied from both sides of the diaphragm valve, opt for the DIASTAR TenPlus. Like the DIASTAR Ten, this valve is easy to install, will not corrode and controls the system flow rate exceptionally well.

Flange Connections

Flange connections are often the best mechanical connection between pipe segments or for installing valves up to very big dimensions.

Installation Fittings

GF Piping Systems has an extensive range of installation fittings available in a wide range of materials, ensuring secure and accurate positioning of sensors and electrodes for exceptional performance. The fittings match perfectly with all GF Signet products and are key for the easy installation of measurement equipment.

Plastic Pipes

Sturdy and lightweight, plastic pipes are ideal for use in a wide range of applications. Versatile yet durable, these all-rounders offer exceptional reliability and proven quality.

Reducers

Reducers are used for effecting a smooth transition between two pipes or fittings with different dimensions. The wide selection available covers an exceptionally diverse area of applications. They are available in short or long versions and in centric or excentric versions.

Saddles

GF Piping Systems produces a range of hard-wearing saddles including branch, clamp-on, strap-on and glue-on variants in various sizes. The saddles are lightweight yet durable, enabling them to support plastic and metal piping systems with ease.

Strainers

Designed to protect sensitive components in piping systems, strainers filter out pollutants from the media. This extends the system’s service life, reduces maintenance, improves operation and minimizes additional expenditure.

Tees, Wyes & Crosses

When creating branch lines, lightweight tee, wye, and cross fittings make installation much easier. These fittings are made from a range of materials and malleable iron and cover multiple dimension possibilities including various reductions on the same fitting.

Unions

Unions are the best mechanical connection between pipe segments and for installing all kinds of components up to the dimensions of d110/DN100. Unions are available in a wide range of materials and jointing options. The connection is fast and very robust.

Ventilating Valve 595

Intended for use in aeration systems, the Ventilating Valve Type 595 ensures safe venting of liquids and gases in the event of negative pressure. This valve is easy to install, while the robust materials and excellent reliability minimize maintenance.

Ventilating and Bleed Valve 591

Light, compact and available for a range of piping configurations and tanks, GF Piping Systems Ventilating & Bleed Valve Type 591 ensures reliable venting of liquids and gases, preventing media backflow and jamming.

Angle Seat Valve 303/304

Both exceptionally reliable and versatile, the type 303/304 angle seat check valves from GF Piping Systems can be installed horizontally or vertically. The check element can be easily serviced without having to dismantle the entire valve.

Cone Check Valve 561/562

The Cone Check Valve 561/562 is designed to prevent the backflow of media into sensitive systems. This valve minimizes pressure loss and comes with a special seal to guarantee leakproof operation.

Ball Valve 546 Pro

The new generation with standard lockable lever, data matrix code and modular design guarantees long-term sustainability. The Ball Valve 546 Pro meets every challenge and application, including simple water applications or complicated processes in the chemical industry, microelectronics or food and beverage industry.

Ball Valve 543

The Ball Valve type 543 is the ideal valve for all mixing and distribution processes, including redirecting, mixing, distributing or even shutting off a medium in areas of application within the chemical process industry, microelectronics or water applications.
