SYGEF Plus PVDF-HP is a high purity polyvinylidene fluoride piping system specifically engineered for applications demanding exceptional purity and stringent particle control. Manufactured under ISO Class 5 (100) cleanroom conditions and double-packaged, it guarantees uncompromised purity from production through to active onsite operation. With continuous improvements, regular leach-out tests that exceed SEMI F57 standards, and seamless quality assurance, it offers maximum reliability. Enhanced by unparalleled jointing technologies and unique high purity features, SYGEF Plus is ideally suited for the most demanding high purity applications.
Size Range:
- d20 - d450 mm ( ½" - 18")
Pressure Rating:
- d20 - d225 mm: PN16 (232 PSI)
- d90 - d450 mm: PN10 (150 PSI)
Operating Temperature:
- -20°C - 140°C (-4°F - 284°F)
Material:
- Polyvinylidene Fluoride (PVDF)
